DNA Products Service Hinged Doors are a 40mm PIR core capped door with a silver anodised aluminium section, fitted to a wrap-around frame section and designed to suit various panel thicknesses. Available as single or double leaf doors.
These service doors offer practical and convenient solutions that meet the requirements and needs of hotels, restaurants, catering businesses, shops and commercial/industrial premises.
The DNA Products Hinged Doors are manufactured to size, to suit customers exact requirements.
Application
Used indoors and outdoors in offices, factories or warehouses, and also in service areas and locker rooms.
These doors can also be used in the health sector, laboratories and places where minimum insulation is needed to preserve the working environment.
Panel
40 mm thick with 40-45 kg/m3 Polyurethane insulation.
Airtight gasket with vertical upper bolt.
Finished in White food-safe as standard.
Fittings
Clamp hinges in A-304 stainless steel.
Inside and outside handle in A-304 stainless steel, lock optional.
Frames
Frames adaptable to any panel thickness using a system of counter frames with side extension.
Aluminium: Frame in extruded aluminium or stainless steel anodised aluminium.
Screws hidden by flashing. Aesthetic, durable finish.
Stainless Steel: Frame and Counter-Frames in A-304 stainless steel.
Finish resistant to chemical products.
Avoids corrosion and ensures perfect cleaning and hygiene.
Panel finish in RAL Colours -------->
Options
Locking handle with Inside turn and release lock, (as for toilets).
Panic Bar Kit.
Glass or methacrylate vision panel.
Silver adjustable overhead Door Closer.
Shoot Bolts fitted to the edge of the static leaf (DOUBLE DOOR ONLY). Protective kick plates can be added upon request: stainless steel, polyethylene, aluminium...
